QT8-15 | Automatic Hydraulic Block Making Machine
It is an automatic hydraulic block-making machine that ensures high quality. DONYUE QT8-15 is engineered for strength and precision. This machine produces many types of blocks. It encompasses hollow, solid, and so on. This makes it a viable option for any building job. The machine operates with a power capacity of 45kW.
It provides a vibration force of 70-100kN, ensuring each block is compacted well and meets the required strength standards. It has a theoretical production capacity of 11,520-15,360 blocks per shift, depending on the block type. This system ensures smooth and reliable operation. It reduces the cost and the need for manual labor. For more details call us at +8801841119091.
Ask for a Quotation!
| Dimension of host machine | 3800*2300*2950mm |
|---|---|
| Weight of host machine | 10.5T |
| Host machine power | 45kW |
| Vibration force | 70-100kN |
| Pallet size | 1050*900*25/30mm |
| Moulding cycle | 15s |
| Size (LxWxH) | Picture | Pcs/Mould | Pcs/Hour | Pcs/Shift |
|---|---|---|---|---|
| 400x200x200mm |  |
8 | 11440-1920 | 11520-15360 |
| 240x115x53mm |  |
45 | 9529-13500 | 76232-108000 |
| 200x100x60mm |  |
28 | 5040-6720 | 40320-53760 |
| 200x163x60mm |  |
20 | 3600-4800 | 28800-38400 |
